3-Axle Sidewall Semi Trailer for Pallet Transport with 30-60 Tons Capacity

تفاصيل المنتج

مكان المنشأ: الصين

اسم العلامة التجارية: SINOTERCEL

شروط الدفع والشحن

الحد الأدنى لكمية: 1 وحدة

الأسعار: قابل للتفاوض

تفاصيل التغليف: الشمع

وقت التسليم: خلال 35 يوم عمل

شروط الدفع: تي/تي

القدرة على العرض: 1000NITS/شهر

احصل على أفضل سعر

تفاصيل المنتج

وصف المنتج

إبراز:

3-Axle Sidewall Semi Trailer for Pallet Transport with 30-60 Tons Capacity

Sidewall Semi Trailer

Product Overview

3-axle pallet transport semi trailer with load capacity of 30-60 tons and length of 13-16 meters. Our best-selling product widely exported to Asia and Africa, including Philippines, Vietnam, Congo, Ethiopia and other regions.

Key Applications

Mechanical equipment transport
Oversized goods handling
Road construction facilities
Large tanks and containers
Power station equipment
Various steel materials

Product Features

Available in 2-axle or 3-axle versions with load range from 20 to 60 tons
Designed specifically for logistics industry with large loading capacity
Light dead weight with excellent cost performance
Optimized by advanced computer-aided design with diverse styles
Custom cargo platform available for special cargo transportation
Wide application and high transport efficiency

Technical Specifications

Parameter	Specification
Product Name	3-Axle Sidewall Semi Trailer, 30-60Ton, 13-16m
Model	3 Axles 60 Tons
Axle	FUWA brand, 16 tons per axle, total 3 sets
Main Beam	Height 500mm, upper plate 10mm, double middle plate 6mm, bottom plate 12mm
Cargo Body Dimension	13000×3000×600mm (Size customizable)
Material	Carbon steel / Manganese steel optional
Gross Vehicle Weight	70000kgs
King Pin	90#
Landing Gear	JOST standard 28T
Suspension	Standard suspension
Leaf Spring Thickness	10/10/10
Tire & Rim	1200R20, 13 tires, 8.5 type 12 rims
Brake Chamber	6 pcs as standard
Spare Wheel Carrier	2 pcs
Tool Box	1 pc
Electrical System	Chinese standard 24V lighting system
Side Marker Light	LED light
Painting	Polyurethane paint
Overall Dimension	16000×2500×3880mm
Color	Customizable as buyer's request
